Mitsubishi FX3U-4AD-TC-ADP FX3U4ADTCADP

Description:

The Mitsubishi FX3U-4AD-TC-ADP Analog Input Adapter is used in industrial automation systems to acquire temperature signals from thermocouple sensors for precise process monitoring. Commonly installed in temperature control systems, furnaces, and manufacturing equipment requiring accurate thermal measurement. Maintenance teams, OEMs, and system integrators use this part for system expansion, retrofit, and replacement of analog input modules.

Applications:

The Mitsubishi FX3U-4AD-TC-ADP is widely used in industrial environments such as heat treatment systems, plastic molding machines, food processing equipment, and environmental control systems where reliable temperature sensing is critical. It enables PLC-based monitoring and control of multiple thermocouple inputs for stable and efficient process management.

Technical Specifications:

• Manufacturer Part Number (MPN): FX3U-4AD-TC-ADP
• Brand: Mitsubishi Electric
• Product Type: Analog Input Adapter (Thermocouple Module)
• Series: MELSEC-FX3U Series
• Number of Channels: 4-channel thermocouple inputs
• Input Type: Thermocouple (various types supported)
• Resolution: High-resolution temperature input
• Conversion Speed: High-speed sampling (model dependent)
• Mounting Type: Direct mount to FX3U PLC
• Power Supply: Supplied from PLC base unit
• Interface: Dedicated adapter connection
• Application: Temperature monitoring and control

Common Replacements:

• Mitsubishi FX2N-4AD-TC
• Mitsubishi FX3U-4AD
• Mitsubishi FX3G-4AD-TC-ADP
