Mitsubishi FX3U-80MR/ES-A PLC MODULE CONTROLLER FX3U80MR/ESA

Description:

The Mitsubishi Q06HCPU is a high-performance PLC CPU unit from the MELSEC-Q series, designed to serve as the central processing unit in modular automation systems. It executes control programs, manages I/O processing, and coordinates communication across the system. Commonly installed in industrial control panels and automation environments, it is used by maintenance teams and system integrators for machine control, system upgrades, and replacement of existing Q-series CPU modules.

Applications:

This Mitsubishi CPU module is used in industrial automation systems requiring high-speed processing and reliable control. Typical applications include manufacturing lines, process control systems, material handling systems, and complex automation environments where fast execution, large program capacity, and stable system performance are critical.

Technical Specifications:

• Manufacturer Part Number (MPN): Q06HCPU
• Product Type: PLC CPU Unit
• Series: MELSEC-Q (QnH Series)
• Program Capacity: 60,000 steps
• I/O Points: Up to 4096 I/O points
• Device Points: Up to 8192 points
• Processing Speed: Approx. 34 ns per instruction (high-speed CPU)
• Program Memory: Approx. 240 KB
• Communication Ports: USB and RS-232
• Memory Support: SRAM, Flash, ATA memory cards
• Power Supply: 5 VDC (from base unit)
• Current Consumption: Approx. 0.64 A
• Mounting Type: Rack-mounted (Q-series base unit)
• Operating Temperature: 0°C to 55°C
• Status: Discontinued (Sept 2018)

Common Replacements:

• Mitsubishi Q06UDEHCPU (modern iQ-Q upgrade)
• Mitsubishi Q06UDHCPU
• Mitsubishi Q03UDVCPU
