Mitsubishi HC-SF102X Servo Motor HCSF102X

Description:

The Mitsubishi HC-SF102X is a 1kW AC servo motor from the high-performance HC-SF series, designed for precision motion control in demanding industrial environments. Operating at a rated speed of 2000 RPM, this motor features a tapered shaft, allowing for high-torque transmission and secure mechanical coupling in applications requiring tight shaft fit. It is ideally paired with MR-J2S servo amplifiers, providing fast response, stable speed control, and reliable performance for use in CNC machines, robotics, and automated material handling systems.

TECHNICAL SPECIFICATIONS:

Model: HC-SF102X
Series: HC-SF
Rated Output Power: 1.0 kW
Rated Speed: 2000 RPM
Rated Torque: 4.77 Nm
Maximum Torque: Approx. 14.3 Nm
Shaft Type: Tapered shaft
Mounting Type: Flange mount
Encoder: Incremental encoder (typically 131072 pulses/rev)
Cooling Method: Natural cooling (self-cooled)
Insulation Class: F
Protection Rating: IP65 (when properly connected)
Power Supply: 3-phase
Compatible Servo Amplifiers: Mitsubishi MR-J2S series
Weight: Approx. 6.5 kg (14.3 lbs)
