Mitsubishi J2-Q05B-F Power Supply Module J2Q05BF

Description:

The Mitsubishi J2‑Q05B‑F power supply module is used in industrial automation systems to provide a stable DC power source for Mitsubishi MELSEC‑J2 series PLCs and I/O modules. It is commonly installed in control panels and machine cabinets to deliver regulated power needed for PLC CPUs and connected field devices. Maintenance teams and system integrators use this module for PLC system builds, power upgrades, and replacement of failed or aging power supplies.

Applications:

The Mitsubishi J2‑Q05B‑F power supply module is widely used in factory and process automation environments that require reliable PLC power. It is commonly found in conveyor systems, packaging machinery, assembly lines, material handling systems, and small‑machine automation where a regulated DC supply ensures stable controller and I/O operation.

Technical Specifications:

• Model: J2‑Q05B‑F
• Module type: PLC power supply unit
• Output voltage: 5 VDC (regulated)
• Output current: Rated output per module specification
• Input voltage: Typically 100–240 VAC (platform dependent)
• Power rating: Industrial PLC power supply class
• Connection: Screw terminal or plug‑in terminals
• Mounting: PLC rack or control panel
• Compatibility: Mitsubishi MELSEC‑J2 series PLC systems
• Indicators: Power ON status LED
• Protection: Overload and short‑circuit protection
• Designed for: Supplying stable low‑voltage DC to PLC logic and I/O
• Operating environment: Industrial temperature range

Common Replacements:

• Mitsubishi J2‑Q10B‑F
• Mitsubishi J2‑Q05B‑E
• Omron S8VS‑05024
