Mitsubishi MELSEC-Q PLC Digital Input Module QX80 MELSECQ

Description:

QX80 INPUT MODULE MELSEC Q-SERIES DIGITAL 16 POINT 24 VDC INPUT Product Description The Mitsubishi QX80 is a digital input module designed for use with Mitsubishi’s MELSEC-Q series PLC systems. This module provides reliable and high-speed digital input functionality, allowing for the connection of various sensors, switches, and devices to monitor the status of industrial systems. The QX80 supports a wide range of industrial automation applications, offering flexibility and ease of integration into control systems requiring precise input monitoring.

Technical Specifications:

• Model Number: QX80
• Type: Digital Input Module
• Number of Inputs: 16 points
• Input Voltage: 24V DC (sink/source)
• Input Current: 7mA per point (at 24V DC)
• Response Time: 0.2 ms (default), can be adjusted in some systems
• Isolation: Photocoupler isolation between input points and internal circuit
• Connector Type: Removable terminal block
• Power Supply: Powered by the main MELSEC-Q PLC system
• Mounting: Rack-mounted on MELSEC-Q series PLC racks
• Operating Temperature: 0°C to +55°C (32°F to 131°F)
• Dimensions: Compact size for easy integration (specific dimensions depend on the model)
