Mitsubishi MR-J2-60B Servo Drive Module MRJ260B

Description:

MRJ260B SERVO DRIVE INPUT: 3.2 AMP 230 VAC 50/60 HZ OUTPUT: 3.6 AMP 170V 0-360 HZ The MR-J2-60B is a robust and efficient AC servo amplifier from Mitsubishi, designed to deliver high precision and reliable performance for industrial automation applications. Ideal for driving AC servo motors in applications such as robotics, CNC machinery, and automated production systems, this amplifier provides smooth and accurate motion control. Featuring advanced control technology and protection features, the MR-J2-60B ensures reliable operation even in demanding environments. Its compact design facilitates easy integration into various systems, making it a valuable component for enhancing the efficiency and effectiveness of automation processes.

Technical Specifications:

• Type: AC Servo Amplifier
• Model: MR-J2-60B
• Rated Output Current: 6.0 A
• Rated Voltage: 200-230V AC
• Power Supply Frequency: 50/60 Hz
• Rated Power Consumption: Approx. 1.2 kVA
• Control Method: PWM (Pulse Width Modulation)
• Feedback Type: Incremental Encoder
• Communication Interface: RS-422/485
• Protection Features: Overcurrent, Overvoltage, Overtemperature, Short Circuit Protection
• Operating Temperature Range: 0°C to 55°C
• Dimensions (LxWxH): 180 mm x 150 mm x 250 mm
• Weight: Approx. 3.5 kg
• Cooling Method: Forced Air Cooling
