Mitsubishi MR-J4-10A+HG-KR13J PLC 200V 100W Servo Amplifier Motor System MRJ410AHGKR13J

Description:

The Mitsubishi MR‑J4‑10A + HG‑KR13J is a combined AC servo amplifier drive and servo motor system used for precise motion control in industrial automation applications. The MR‑J4‑10A drive controls the HG‑KR13J motor to deliver accurate positioning, responsive torque, and smooth speed regulation. Commonly installed in CNC machines, robotic systems, automated conveyors, and packaging equipment, this servo system supports demanding motion tasks. Maintenance teams, system integrators, and OEMs use this drive/motor system for new automation builds, system upgrades, replacements, and applications requiring dependable motion performance and tight feedback control.

Applications:

This Mitsubishi servo amplifier and motor system is used in industrial environments requiring high‑quality motion control and precise positioning. Typical applications include CNC machining centers, robotic arms, pick‑and‑place equipment, automated assembly lines, packaging machinery, and material handling systems where coordinated speed and position control are essential for operational efficiency and product accuracy.

Technical Specifications:

• Manufacturer Part Number (MPN): MR‑J4‑10A + HG‑KR13J
• Product Type: AC Servo Amplifier Drive + Servo Motor System
• Drive Output Current: 10 A
• Motor Power: 100 W
• Power Supply: 200 VAC (drive)
• Frequency: 50/60 Hz
• Control Method: Closed‑loop control via encoder feedback
• Motor Rated Torque: Approx. 0.32 Nm
• Motor Rated Speed: Approx. 3000 RPM
• Maximum Speed: Approx. 4500 RPM
• Feedback: Integrated motor encoder
• Protection Features: Overcurrent, overvoltage, overheat protection
• Cooling Method: Drive ‑ built‑in fan; Motor ‑ self‑ventilated
• Mounting Type: Drive panel mount / Motor flange mount
• Operating Temperature: 0 °C to 50 °C
• Storage Temperature: ‑20 °C to 65 °C
• Protection Class: IP20 (drive), IP65 (motor)

Common Replacements:

• Mitsubishi MR‑J4‑10A + HG‑KP13J (alternate servo motor pairing)
• Yaskawa Sigma‑7 Servo Drive + SGM7J‑02A Motor
• Panasonic MINAS A5 Servo Drive + Motor 100 W
