Mitsubishi
Mitsubishi NV63-SV 3P 40A Circuit Breaker NV63SV
Mitsubishi NV63-SV 3P 40A Circuit Breaker NV63SV
Couldn't load pickup availability
Description:
NV63SV3P40A30 EARTH LEAKAGE BREAKER 3P 40A 30MA The NV63-SV 3P 40A is a high-performance, three-phase circuit breaker designed for robust electrical protection in industrial and commercial settings. With a rated current of 40 amps, this circuit breaker provides reliable overcurrent protection and short-circuit protection for three-phase electrical systems. The NV63-SV 3P features a compact and durable design, equipped with a thermal-magnetic trip mechanism that ensures accurate and responsive protection. Its user-friendly interface includes an adjustable trip setting, making it adaptable to varying load conditions. Additionally, the circuit breaker is designed for easy installation and maintenance, offering enhanced safety and reliability for critical electrical applications.
Technical Specifications:
- Model: NV63-SV 3P 40A
- Type: Three-Phase Circuit Breaker
- Rated Current: 40 Amps
- Poles: 3 (Three-Phase)
- Trip Mechanism: Thermal-Magnetic
- Voltage Rating: 400V AC
- Breaking Capacity: 10kA
- Adjustable Trip Setting: Yes
- Operating Temperature Range: -5°C to 40°C
- Dimensions: 4.5 x 4.0 x 3.5 inches
- Weight: 1.2 lbs
- Mounting Type: Din Rail Mount
- Certifications: CE, UL
