Mitsubishi OSE105S2 Rotary Encoder OSE105S2

Description:

The OSE105S2 is a safety light curtain transmitter used in conjunction with a matching receiver for personnel protection and machine guarding applications. It operates at 24V DC and is designed to detect the interruption of an infrared light beam across an open area up to 5 meters wide. With its rugged housing and IP65 rating, the OSE105S2 is suitable for industrial environments requiring reliable and responsive presence detection to ensure operator safety.

TECHNICAL SPECIFICATIONS:

Model: OSE105S2
Type: Safety Light Curtain Transmitter
Sensing Range: Up to 5 meters
Voltage: 24V DC
Light Source: Infrared LED
Connection Type: Pre-wired cable or connector (depending on variant)
Mounting: Vertical or horizontal, bracket-compatible
Protection Rating: IP65
Operating Temperature: –25°C to +55°C (–13°F to +131°F)
Housing Material: Metal or high-impact plastic (model dependent)
Certifications: CE, cULus, TUV (Type 2 safety rated, depending on complete system)
Compatibility: Requires matching OSE receiver unit for full operation
Applications: Access control, point-of-operation guarding, area protection
