Mitsubishi PM150CBS060 Power Module Supply PM150CBS060

Description:

The Mitsubishi PM150CBS060 Power Module Supply is used in industrial inverter and servo drive power stages for motor control and power conversion systems. Commonly installed in variable frequency drives, servo amplifiers, CNC machinery, and factory automation equipment requiring intelligent power modules. Maintenance teams, OEMs, and system integrators use this module for replacement, repair, or power stage restoration to maintain reliable drive operation and prevent equipment downtime.

Applications:

The Mitsubishi PM150CBS060 Used in industrial inverter drives, servo drive amplifiers, motor control systems, CNC spindle drives, HVAC industrial drives, material handling equipment, packaging machinery, and factory automation systems requiring IGBT-based intelligent power modules for controlled motor output.

Technical Specifications:

• Brand: Mitsubishi
• Part Number: PM150CBS060
• Product Type: Intelligent Power Module (IPM)
• Module Type: IGBT Power Module
• Rated Current: 150A class
• Voltage Class: 600V
• Configuration: 3-phase inverter bridge
• Built-in Protection: Overcurrent, overtemperature, undervoltage
• Drive Type: AC motor / inverter drive applications
• Mounting: Screw mount power module
• Cooling: Heatsink required
• Control Interface: Integrated gate drive circuit
• Insulation: Isolated baseplate
• Application: Industrial motor drive power stage

Common Replacements:

• Mitsubishi PM150CSA060
• Mitsubishi PM100CBS060
• Mitsubishi CM150DY-24A
