Mitsubishi Programmable Controller PLC FX3U-128MR/ES-A FX3U128MRESA

Description:

FX3U128MRESA LOGIC MODULE MAIN UNIT FX3U SERIES 100-240 VAC 50/60 HZ 65 WATTS OUTPUT 30 VDC/240 VAC 2 AMP 64 INPUTS 24 VDC 64 RELAY OUTPUTS 256 LOCAL I/O POINTS 384 LOCAL + REMOTE I/O POINTS EXPANDABLE IP10 PROTECTION SCREW TERMINALS DIN RAIL MOUNT The FX3U-128MR/ES-A is a high-performance and expandable programmable logic controller (PLC) from Mitsubishi Electric, designed for complex and versatile automation tasks. This model features 128 relay outputs and integrates advanced functions for precise control and monitoring in a variety of industrial applications. With its enhanced processing power and expansion capabilities, the FX3U-128MR/ES-A is ideal for use in sophisticated machine control systems, process automation, and data acquisition. Its robust design and user-friendly programming environment ensure reliable performance and ease of integration into various automation setups. Type: Compact PLC Model: FX3U-128MR/ES-A Number of Inputs: 64 digital inputs Number of Outputs: 64 relay outputs Input Voltage: 24V DC Output Voltage: 240V AC Rated Output Current: 2A per relay Program Memory: 16K steps Communication Interface: RS-422/485, Ethernet (via optional modules) Operating Temperature Range: 0°C to 55°C Dimensions: 160mm x 90mm x 120mm Weight: 600g Mounting: DIN rail mount Protection Class: IP20
