Mitsubishi Q38DB Base Unit Q38DB

Description:

Q38DB IQ PLATFORM BASE UNIT 8 SLOT The Q38DB is a high-performance digital I/O module designed for Mitsubishi Electric's Q Series PLC systems. It provides 16 digital inputs and 16 digital outputs, allowing for versatile control and monitoring of industrial processes. This module is engineered for fast and reliable data processing, supporting a wide range of automation tasks including sensor interfacing, relay control, and signal monitoring. Its robust construction and high-speed operation make it suitable for use in demanding industrial environments where precision and durability are crucial.

Technical Specifications:

• Model: Q38DB
• Input type: 16 digital inputs (24 V DC)
• Output type: 16 digital outputs (24 V DC, transistor)
• Input response time: 0.2 ms (OFF to ON) / 0.5 ms (ON to OFF)
• Output response time: 0.1 ms (ON to OFF) / 0.2 ms (OFF to ON)
• Input current: 7 mA
• Output current: 0.5 A per point
• Isolation: Photocoupler isolation for inputs and outputs
• Power consumption: 5 W
• Dimensions: 90 mm x 90 mm x 90 mm
• Weight: 0.5 kg
• Operating temperature range: 0°C to 55°C
• Mounting type: DIN rail
