Mitsubishi Q68DAVN PLC Module Q68DAVN

Description:

The Mitsubishi CM450DY24S is a power transistor module used in industrial automation and power electronics systems for high-current switching and efficient power control. Commonly installed in variable frequency drives (VFDs), inverter systems, motor drives, and industrial power supplies, it enables reliable switching performance and thermal stability in demanding applications. Maintenance teams, system integrators, and OEMs use this module for replacements, upgrades, and power system repairs where dependable high-power semiconductor operation is required.

Applications:

This Mitsubishi power transistor module is used in industrial environments requiring efficient high-power switching and energy conversion. Typical applications include AC motor drives, VFDs, inverter circuits, UPS systems, welding equipment, and renewable energy power systems where stable switching performance, thermal management, and high current handling are essential for maintaining system reliability and efficiency.

Technical Specifications:

• Manufacturer Part Number (MPN): CM450DY24S
• Product Type: Power Transistor Module (IGBT/Hybrid module class)
• Rated Voltage: Approx. 1200–1400 V class (series dependent)
• Rated Current: Approx. 450 A class
• Configuration: Dual transistor module
• Switching Type: High-speed power switching
• Package Type: Industrial power module (baseplate/heatsink mount)
• Mounting Type: Heatsink mount
• Thermal Resistance: Low thermal resistance for high-power dissipation
• Cooling Method: External heatsink required
• Operating Temperature: -40 °C to 150 °C (junction)
• Storage Temperature: -55 °C to 175 °C
• Insulation: Electrically isolated baseplate
• Application Class: Motor drives, inverters, power converters

Common Replacements:

• Mitsubishi CM450DY24H
• Infineon FF450R12KT4
• Semikron SKM400GB12T4
