NEW SQUARE D POWERPACT 15 AMP I-LINE CIRCUIT BREAKER 600 VAC 3 POLE BJA36015

Description:

The Square D BJA36015 is a 3-pole molded case circuit breaker rated for 15 Amps. Part of the BJA series from Schneider Electric, it is designed for use in panelboards and switchboards in commercial and industrial environments. This unit provides reliable circuit protection and features a compact frame suitable for space-constrained installations, offering bolt-on mounting for secure connection.

TECHNICAL SPECIFICATIONS:
Manufacturer: Square D / Schneider Electric
Model Number: BJA36015
Series: BJA
Type: Molded Case Circuit Breaker
Mounting Style: Bolt-On
Poles: 3
Amperage Rating: 15 Amps
Voltage Rating: 600Y/347V AC
Interrupting Rating: 14 kA at 480Y/277V AC
Frame Size: 125 Amp frame
Connection: Line and load side lugs
Trip Type: Thermal magnetic
Standards: UL Listed, CSA Certified
Application: Commercial and industrial power distribution
