Omron Automation CJ1G-CPU43H Programmable Logic Controller CPU Unit CJ1GCPU43H

Description:

CJ1GCPU43H CPU MODULE 20K STEPS 64K WORDS MEMORY SYSMAC The CJ1G-CPU43H is a high-performance central processing unit (CPU) from Omron's CJ1G series, designed to offer advanced control and automation capabilities for complex industrial applications. Featuring a powerful 32-bit microprocessor, this CPU provides high-speed processing with a scan time of approximately 0.08 ms per 1,000 instructions. It includes 16K steps of program memory and 8K words of data memory, ensuring ample space for complex programs and data handling. With integrated communication ports and support for expansion units, the CJ1G-CPU43H is ideal for large-scale automation systems requiring robust performance and flexibility.

Technical Specifications:

• Model: CJ1G-CPU43H
• Type: Programmable Logic Controller (PLC) CPU Unit
• Processor Type: 32-bit microprocessor
• Program Memory: 16K steps
• Data Memory: 8K words
• I/O Capacity: Supports up to 512 digital I/O points and 256 analog I/O points (with expansion units)
• Communication Ports:
• Built-in Serial Ports: 1 (RS-232C/RS-422/RS-485, selectable)
• Ethernet Port: 1 (for network communication and remote access)
• Scan Time: Approx. 0.08 ms per 1,000 instructions (typical)
• Operating Voltage: 24V DC
• Current Consumption: 600 mA (typical)
• Operating Temperature Range: 0°C to +55°C
• Storage Temperature Range: -25°C to +70°C
• Dimensions (W x H x D): 160 x 120 x 90 mm
• Weight: Approximately 800 g
• Mounting Type: DIN rail mountable
• Compliance: RoHS compliant
