Omron CJ1M-CPU11 CJ1MCPU11

Description:

CJ1MCPU11ETN DISCONTINUED BY MANUFACTURER CPU UNIT WITH BUILT-IN ETHERNET DIN RAIL MOUNT The CJ1M-CPU11-ETN is a high-performance central processing unit (CPU) from Omron’s CJ1M series, tailored for demanding industrial automation applications. This model features a robust 32-bit processor with a scan time of approximately 0.08 ms per 1,000 instructions, ensuring fast and efficient processing of complex tasks. It includes 8K steps of program memory and 4K words of data memory, providing ample resources for comprehensive automation programs. The "ETN" suffix indicates that this CPU comes with an integrated Ethernet port, facilitating seamless network communication and remote access, making it ideal for modern, networked automation systems.

Technical Specifications:

• Model: CJ1M-CPU11-ETN
• Type: Programmable Logic Controller (PLC) CPU Unit
• Processor Type: 32-bit microprocessor
• Program Memory: 8K steps
• Data Memory: 4K words
• I/O Capacity: Supports up to 128 digital I/O points and 64 analog I/O points (with expansion units)
• Communication Ports:
• Built-in Ethernet Port: 1 (for network communication and remote access)
• Built-in Serial Ports: 1 (RS-232C/RS-422/RS-485, selectable)
• Scan Time: Approx. 0.08 ms per 1,000 instructions (typical)
• Operating Voltage: 24V DC
• Current Consumption: 300 mA (typical)
• Operating Temperature Range: 0°C to +55°C
• Storage Temperature Range: -25°C to +70°C
• Dimensions (W x H x D): 90 x 90 x 80 mm
• Weight: Approximately 350 g
• Mounting Type: DIN rail mountable
• Compliance: RoHS compliant
