Omron CJ1W-NC233 PLC Module CJ1WNC233

Description:

The Omron CJ1W-NC233 is a high-precision position control unit designed for use with the CJ1 series PLCs. This module supports 2-axis positioning using pulse train outputs and is ideal for controlling servo or stepper motors in automated machinery. It offers advanced motion control features such as linear interpolation, speed and acceleration control, and high-speed pulse outputs up to 1 MHz. With easy integration into the CJ1 PLC system and configuration via Omron’s CX-Programmer or CX-Motion software, the CJ1W-NC233 provides reliable, real-time control in applications such as packaging, labeling, material handling, and robotics.

Technical Specifications:

Module Type: Position Control Unit
Series: CJ1
Model: CJ1W-NC233
Number of Controlled Axes: 2
Control Method: Pulse Train Output
Pulse Output Frequency: Up to 1 MHz
Output Format: CW/CCW or Pulse/Direction
Compatible Motors: Servo motors and stepper motors with pulse input
Interpolation: Linear (2-axis)
Positioning Methods: Absolute, Relative, Continuous, Origin Search
Power Supply: Supplied from CJ1 PLC rack
Mounting: CJ1 Backplane
Configuration Software: CX-Programmer, CX-Motion
LED Indicators: Axis status, error, and communication indicators
Operating Temperature Range: 0°C to 55°C (32°F to 131°F)
Dimensions: 31 mm x 100 mm x 90 mm (W x H x D approx.)
Weight: Approx. 200 g (7 oz)
