Omron CJ1W-NC482 Position Controller CJ1WNC482

Description:

CJ1WNC482 POSITION CONTROLLER UNIT 4 AXIS 64 NODES ETHERCAT MASTER The CJ1W-NC482 is a high-precision pulse input unit from Omron’s CJ1 series, designed to provide reliable and accurate counting and measurement for industrial automation applications. This module features 4 pulse input channels, each capable of processing high-speed pulse signals with a frequency of up to 100 kHz. It is ideal for applications involving position control, speed detection, and high-speed counting. With its robust design and compatibility with CJ1 series PLCs, the CJ1W-NC482 integrates seamlessly into automation systems, enhancing functionality and control for complex tasks.

Technical Specifications:

• The CJ1W-NC482 is a high-precision pulse input unit from Omron’s CJ1 series, designed to provide reliable and accurate counting and measurement for industrial automation applications. This module features 4 pulse input channels, each capable of processing high-speed pulse signals with a frequency of up to 100 kHz. It is ideal for applications involving position control, speed detection, and high-speed counting. With its robust design and compatibility with CJ1 series PLCs, the CJ1W-NC482 integrates seamlessly into automation systems, enhancing functionality and control for complex tasks.
• Model: CJ1W-NC482
• Type: Pulse Input Unit
• Channels: 4 channels
• Input Method: Differential line driver (compatible with incremental encoders)
• Pulse Input Frequency: Up to 100 kHz per channel
• Pulse Counting Range: 32-bit counting (per channel)
• Input Voltage Range: 5V to 24V DC
• Current Consumption: 100 mA (typical)
• Operating Temperature Range: 0°C to +55°C
• Storage Temperature Range: -25°C to +70°C
• Dimensions (W x H x D): 90 x 90 x 80 mm
• Weight: Approximately 200 g
• Mounting Type: Directly mounts on CJ1 series PLC racks
• Environmental Protection: IP20 (dust-tight, protected against solid objects greater than 12 mm)
• Compliance: RoHS compliant
