Omron CJ1W-OD203 PLC Module CJ1WOD203

Description:

CJ1WOD203 OUTPUT MODULE 8 OUTPUTS 8 POINTS (1 COMMON) 12-24 VDC 0.5 AMP REMOVABLE TERMINAL BLOCK The Omron CJ1W-OD203 is a digital output unit designed for use with Omron CJ1 series PLCs (Programmable Logic Controllers). This module offers high flexibility and reliability for industrial automation tasks by providing 16 digital outputs in a compact and robust package. It is well-suited for controlling various external devices and machinery, with each output capable of switching substantial loads. The CJ1W-OD203 module integrates seamlessly with the CJ1 PLC series, facilitating efficient and effective control over diverse applications.

Technical Specifications:

• Model Number: CJ1W-OD203
• Type: Digital Output Unit
• Compatibility: Omron CJ1 Series PLCs
• Number of Outputs: 16 Digital Outputs
• Output Type: Transistor Output
• Output Voltage: 24V DC
• Output Current:
• Per Channel: 0.5A
• Total Current (All Channels): 8A
• Output Type: NPN (Sinking) / PNP (Sourcing) selectable (depends on the configuration)
• Response Time: Typically 1ms (ON) / 1ms (OFF)
• Insulation Resistance: 1000 MΩ at 500V DC
• Dielectric Strength: 2000V AC for 1 minute
• Mounting Type: Mounts on the CJ1 series backplane
• Connector Type: Spring clamp terminals
• Operating Temperature Range: 0°C to 55°C
• Storage Temperature Range: -20°C to 70°C
• Features: High-density outputs, reliable switching performance, easy integration with CJ1 PLCs, and robust construction for industrial environments
