Omron CJ1W-OD213 CJ1WOD213

Description:

The Omron CJ1W-OD213 Output Module is used in CJ1 series PLC systems for high-speed digital output control in industrial automation applications. Commonly installed in packaging machines, conveyor systems, assembly lines, and automated equipment requiring reliable transistor-based output switching. Maintenance teams, OEMs, and system integrators use this part for system expansion, replacement, retrofit, and maintaining efficient control operations.

Applications:

The Omron CJ1W-OD213 output module is used in industrial environments to control external devices such as solenoids, relays, contactors, and indicator systems. It is widely applied in manufacturing lines, automated machinery, and process control systems where fast and precise digital output switching is required.

Technical Specifications:

• Manufacturer Part Number (MPN): CJ1W-OD213
• Product Type: Digital Output Module (PLC Expansion Module)
• Series: CJ1
• Number of Outputs: 32 digital outputs
• Output Type: Transistor (sinking)
• Rated Output Voltage: 24 VDC
• Maximum Load Current: Approx. 0.3 A per point
• Output Configuration: Common terminal groups
• Response Time: High-speed switching
• Isolation: Photocoupler isolation
• Mounting Type: Rack-mounted (CJ1 PLC system)
• Compatible PLC: Omron CJ1 series
• Operating Temperature: 0°C to 55°C

Common Replacements:

• Omron CJ1W-OD212
• Omron CJ1W-OD211
• Omron CJ1W-OD231
