Omron CJ1W-V600C11 ID Sensor Unit CJ1WV600C11

Description:

CJ1WV600C11 CONTROLLER CJ1 SINGLE HEAD RFID MODULE The CJ1W-V600C11 ID is a high-performance, high-density I/O unit from Omron’s CJ1 series, designed to expand the I/O capabilities of CJ1-series PLCs (Programmable Logic Controllers). This module offers 16 digital inputs and 16 digital outputs in a single, compact unit, providing a comprehensive solution for managing a large number of discrete signals. The CJ1W-V600C11 ID is designed for reliability and ease of integration, featuring high-speed data processing and a robust construction to withstand industrial environments. It supports standard 24V DC I/O signals and is equipped with LED indicators for easy monitoring of input and output statuses. The unit’s high-density design helps optimize panel space while enhancing system functionality.

Technical Specifications:

• Model: CJ1W-V600C11 ID
• Type: Digital I/O Expansion Unit
• Compatibility: Omron CJ1 series PLCs
• I/O Points:
• Inputs: 16 channels, 24V DC
• Outputs: 16 channels, 24V DC
• Input Type: Sinking (NPN) or sourcing (PNP), selectable
• Output Type: Transistor outputs
• Input/Output Response Time:
• Input: 1 ms (typical)
• Output: 1 ms (typical)
• Data Processing Speed: High-speed data processing
• Mounting: Directly mounts onto the CJ1 PLC base unit
• Dimensions (W x H x D): 90 x 90 x 80 mm (approx.)
• Weight: 0.4 kg (approx.)
• Environmental Conditions: Operating temperature range of 0°C to 55°C (32°F to 131°F), relative humidity up to 85%
• Protection Rating: IP20
• Certification: CE
