Omron CP1E-N20DT1-D PLC CPU Unit CP1EN20DT1D

Description:

CP1EN20DT1D CPU UNIT CP-SERIES 0.3 AMP 24 VDC APPLICATION MODEL 8 INPUTS 6 INPUTS DC INPUTS TRANSISTOR OUTPUTS SINKING DC POWER SUPPLY RS-232C PORT 8K STEPS PROGRAM CAPACITY 8K WORDS DATA MEMORY The CP1E-N20DT1-D is a versatile and compact programmable logic controller (PLC) from Omron’s CP1E series, designed to handle a variety of industrial automation tasks with efficiency and reliability. This model features 20 I/O points, including 12 digital inputs and 8 digital outputs, which allows for direct control of devices and sensors in small to medium-sized applications. The CP1E-N20DT1-D includes a built-in RS-232C communication port for straightforward integration into existing control systems. Its compact size, ease of programming, and flexible expansion options make it a robust choice for diverse automation needs.

Technical Specifications:

• Model: CP1E-N20DT1-D
• Type: Programmable Logic Controller (PLC)
• I/O Configuration:
• Digital Inputs: 12 points (24V DC)
• Digital Outputs: 8 points (Relay type, 24V DC)
• Program Memory: 2K steps
• Data Memory: 1K words
• Communication Ports:
• Built-in Serial Port: 1 (RS-232C for communication)
• Operating Voltage: 24V DC
• Current Consumption: 400 mA (typical)
• Operating Temperature Range: 0°C to +55°C
• Storage Temperature Range: -25°C to +70°C
• Dimensions (W x H x D): 60 x 90 x 75 mm
• Weight: Approximately 300 g
• Mounting Type: DIN rail mountable
• Environmental Protection: IP20 (dust-tight, protected against solid objects greater than 12 mm)
• Compliance: RoHS compliant
