Omron CP1L-L14DT1-D High Performing Programmable Controller w/ Embedded Ethernet CP1LL14DT1D

Description:

The Omron CP1L-L14DT1-D programmable controller is used in CP1L-series automation systems to execute control logic and manage high-speed I/O with embedded Ethernet communication in industrial equipment. Commonly installed in packaging machines, conveyor systems, small assembly lines, and OEM machinery requiring compact PLC control with network connectivity. Maintenance teams and system integrators use this part for replacement, retrofit, and maintaining efficient automation and communication in industrial systems.

Applications:

The Omron CP1L-L14DT1-D PLC is used in industrial environments where compact control with built-in Ethernet communication is essential. It is applied in material handling systems, packaging equipment, machine automation, and small production lines to control processes, enable remote monitoring, and integrate seamlessly with networked automation systems.

Technical Specifications:

• Manufacturer: Omron
• Part Number: CP1L-L14DT1-D
• Product Type: PLC CPU Module with Embedded Ethernet
• Series: Omron CP1L Series
• I/O Points: 14 total I/O (8 inputs, 6 transistor outputs)
• Output Type: Transistor output (sourcing)
• Power Supply: 24 VDC
• Program Capacity: Approx. 10K steps
• Communication Ports: Ethernet, USB, RS-232C
• Functions: High-speed counters, pulse outputs for motion control
• Expansion Capability: Supports CP1W expansion units
• Mounting Type: DIN rail mount
• Connection Type: Screw terminal
• Operating Temperature: 0°C to +55°C

Common Replacements:

• Omron CP1L-M30DT1-D PLC CPU Module
• Omron CP1E-N30DT-D PLC Module
• Omron CJ2M-CPU11 PLC CPU Module
