Omron D4JL-2NFA-D6 Guard Lock Safety D4JL2NFAD6

Description:

The Omron D4JL-2NFA-D6 guard lock safety switch is used in industrial safety systems to monitor and control access to hazardous machinery through safety door interlocking. Commonly installed in robotic cells, packaging machines, CNC equipment, and automated production lines requiring secure guard locking. Maintenance teams and system integrators use this part for replacement, retrofit, and ensuring compliance with machine safety standards.

Applications:

The Omron D4JL-2NFA-D6 safety switch is used in industrial environments to protect operators by preventing machine operation when safety guards are open. It is widely applied in manufacturing lines, assembly systems, material handling equipment, and processing machines where controlled access and safety interlocking are critical for safe operation.

Technical Specifications:

• Manufacturer Part Number (MPN): D4JL-2NFA-D6
• Product Type: Guard Lock Safety Switch
• Series: D4JL Series
• Operation Type: Mechanical interlock with solenoid guard lock
• Contact Configuration: 2NC + 1NO
• Head Type: Key-operated actuator
• Lock Type: Power-to-lock or power-to-release (model dependent)
• Rated Voltage: Up to 240 VAC / 250 VDC
• Rated Current: Approx. 3 A (AC-15), 2 A (DC-13)
• Connection Type: Pre-wired cable (6 m length)
• Mounting Type: Panel/door mount
• Protection Rating: IP67
• Operating Temperature: -10°C to +55°C
• Standards Compliance: ISO 14119, IEC/EN 60947-5-1

Common Replacements:

• Omron D4NL-2NFA-B
• Omron D4SL-N2NFA-D
• Omron D4NS-2AF
