Omron D4NL-2ADA-B Guard Lock Safety Limit Switch D4NL2ADAB

Description:

D4NL2ADAB SAFETY DOOR SWITCH GUARD-LOCK LIGHT EMITTING DIODE (LED) 10 TO 115 AC/DC VOLTAGE The Omron D4NL-2ADA-B is a guard lock safety limit switch designed for use in industrial safety applications. This device features a robust and compact design that ensures reliable performance in securing safety doors and gates. The D4NL-2ADA-B integrates a mechanical lock mechanism to prevent the door from opening until the safety conditions are met, providing an effective safeguard against unauthorized access and ensuring operational safety.

Technical Specifications:

• Model Number: D4NL-2ADA-B
• Type: Guard Lock Safety Limit Switch
• Function: Mechanical lock with limit switch functionality
• Contact Configuration: 2NC (Normally Closed) / 1NO (Normally Open) + 1NC (Normally Closed)
• Operating Principle: Mechanical lock with safety switch
• Rated Operating Voltage:
• AC: 240V AC
• DC: 24V DC
• Rated Operating Current:
• AC: 3A
• DC: 2A
• Mechanical Durability: 1,000,000 operations
• Electrical Durability: 100,000 operations at rated load
• Operating Temperature Range: -10°C to 55°C
• Storage Temperature Range: -25°C to 65°C
• Degree of Protection: IP67 (dust-tight and protected against immersion in water)
• Body Material: Die-cast zinc alloy
• Actuator Type: Roller plunger
• Mounting Type: Panel mount or surface mount
• Safety Compliance:
• Conforms to relevant safety standards such as ISO 13849-1 and IEC 61508 for functional safety.
