Omron DRT2-AD04 SMART SLAVE 4 ANALOG INPUTS Lead Free RoHS Compliant DRT2AD04

DESCRIPTION

The Omron DRT2-AD04 is a high-precision 4-channel analog input module designed for use on a DeviceNet network. It allows the acquisition of analog voltage or current signals and transmits them digitally to a host controller via the DeviceNet protocol. With 16-bit resolution and features like scaling, alarms, and diagnostics built-in, the DRT2-AD04 is ideal for applications requiring accurate analog data acquisition in distributed I/O systems. The compact and DIN-rail-mountable design makes it easy to integrate into industrial control panels and machine automation setups.

TECHNICAL SPECIFICATIONS

Model: DRT2-AD04
Input Channels: 4 analog inputs
Input Type: Voltage (±10V, 0–10V) or Current (4–20mA, 0–20mA)
Resolution: 16-bit
Network: DeviceNet
Status Indicators: Power, Network, and Module status LEDs
Mounting: DIN Rail
Power Supply: 24 VDC
Operating Temperature: 0 to 55°C
Dimensions (W x H x D): Approx. 30 x 90 x 80 mm
Protection Rating: IP20
Connector Type: Removable terminal block
Additional Features:
– Alarm setting per channel
– Input signal averaging
– Disconnection detection
