Omron E2C-X5AH Proximity Sensor E2CX5AH

Description:

The Omron E2C-X5AH Proximity Sensor is used in industrial automation systems for non-contact displacement and position detection using high-precision capacitive sensing technology. Commonly installed in semiconductor equipment, precision assembly machines, inspection systems, and automated production lines requiring accurate detection of small movements or non-metal objects. Maintenance teams and system integrators use this part for replacement, retrofit, and maintaining reliable sensing performance in precision applications.

Applications:

The Omron E2C-X5AH proximity sensor is applied in processes where high-resolution detection and stability are critical. It is widely used in electronics manufacturing, wafer handling systems, packaging inspection, and fine positioning equipment. This sensor enables accurate detection of various materials including plastics, liquids, and thin objects, making it suitable for sensitive and high-precision industrial environments.

Technical Specifications:

• Brand: Omron
• Part Number: E2C-X5AH
• Product Type: Capacitive Proximity Sensor Amplifier Unit
• Sensing Method: Capacitive displacement detection
• Sensing Range: Up to 5 mm (model dependent)
• Output Type: Analog output
• Power Supply: 12 to 24 VDC
• Response Time: High-speed response
• Sensitivity Adjustment: Fine manual adjustment
• Compatible Sensor Heads: Omron E2C series sensing heads
• Protection Rating: IP40 (amplifier unit)
• Mounting Type: DIN rail mounting
• Features: High precision detection, stable output, compact design

Common Replacements:

• Omron E2C-X10A
• Omron E2C-EDA11
• Omron E2CA-X5A
