Omron E3B2-R5M4D-US-3 Photoelectric Switch Sensor E3B2R5M4DUS3

Description:

The Omron E3B2-R5M4D-US-3 photoelectric switch sensor is used in industrial automation systems for long-distance object detection and presence sensing. Commonly installed in conveyor systems, packaging lines, material handling equipment, and production lines requiring reliable through-beam or retro-reflective detection. Maintenance teams and system integrators use this part for replacement, retrofit, and maintaining consistent sensing performance in demanding industrial environments.

Applications:

The Omron E3B2-R5M4D-US-3 photoelectric sensor is used in industrial environments for detecting objects over longer distances, positioning, and counting applications. It is widely applied in logistics systems, bottling plants, warehouse automation, and heavy-duty manufacturing where durable sensing and stable detection performance are required.

Technical Specifications:

• Manufacturer Part Number (MPN): E3B2-R5M4D-US-3
• Product Type: Photoelectric Sensor (Retro-reflective)
• Series: E3B2 Series
• Sensing Distance: Up to approx. 5 meters
• Light Source: Infrared LED
• Output Type: NPN output
• Supply Voltage: 12 to 24 VDC
• Connection Type: Pre-wired cable
• Housing Type: Rectangular / heavy-duty housing
• Protection Rating: IP67
• Response Time: Fast response (milliseconds range)
• Operating Temperature: -25°C to +55°C
• Protection Features: Reverse polarity, short circuit protection

Common Replacements:

• Omron E3JK-RR12
• Omron E3FA-RN12
• Autonics BR100-DDT
