Omron

Omron E5CS-Q1KJX-522 Temperature Controller E5CSQ1KJX522

Omron E5CS-Q1KJX-522 Temperature Controller E5CSQ1KJX522

Condition
Regular price $369.00
Regular price Sale price $369.00
Sale Sold out
PayPal Google Pay Visa MasterCard Amex Venmo

Description:

E5CSQ1KJX522 DISCONTINUED BY MANUFACTURER 1/16 DIN TEMPERATURE CONTROL 20MA 100-240VAC 12VDC The E5CS-Q1KJX-522 is a versatile and high-performance digital temperature controller from Omron's E5CS series, engineered for precise temperature control and monitoring in a range of industrial applications. This model features a clear LCD display that allows for easy reading and adjustment of temperature settings. With advanced PID control algorithms, the E5CS-Q1KJX-522 ensures accurate and stable temperature regulation, enhancing the efficiency and reliability of your processes. It supports multiple input types, including thermocouples and RTDs, and offers multiple output options such as relay and SSR control. Its user-friendly interface and robust performance make it suitable for demanding temperature control applications.

Technical Specifications:

  • Model: E5CS-Q1KJX-522
  • Display Type: LCD, backlit
  • Display Size: 48 x 48 mm
  • Input Type: Thermocouple (K, J, T, R, S, B), RTD (Pt100), or voltage/current inputs
  • Control Output: Relay (SPST-NO), SSR control, or 4-20mA output (selectable)
  • Control Method: PID, ON/OFF
  • Temperature Range: -199.9°C to 1999°C (depending on input type)
  • Accuracy: ±0.3°C or ±0.1% of span
  • Resolution: 1°C or 0.1°C (selectable)
  • Alarm Functions: Up to 2 alarms (high/low, deviation)
  • Communication Ports: Optional RS-485 (Modbus RTU) with additional communication module
  • Operating Temperature Range: 0°C to +55°C
  • Storage Temperature Range: -20°C to +75°C
  • Dimensions: 48mm x 48mm x 88mm (W x H x D)
  • Weight: Approximately 0.2 kg
  • Mounting: Panel mount (cutout size: 45mm x 45mm)
  • Certification: CE, UL
