Omron E6A2-CS5C 60P/R Rotary Encoder E6A2CS5C

Description:

E6A2CS5C60PR05M INC 12-24VDC OPEN A PHASE The Omron E6A2-CS5C is a high-precision rotary encoder designed to provide accurate position and speed feedback in various industrial automation applications. Featuring a 60 pulses per revolution (PPR) resolution, this encoder offers fine granularity for precise measurement and control of rotary motion. Its compact and robust design ensures reliable operation even in harsh environments, with a durable construction that stands up to dust and moisture. The E6A2-CS5C uses incremental encoding technology to deliver consistent and reliable output, making it suitable for applications such as motor feedback, conveyor systems, and robotic positioning. Its easy integration with standard control systems and long operational life make it a versatile choice for enhancing motion control and automation processes.

Technical Specifications:

• Type: Incremental Rotary Encoder
• Resolution: 60 pulses per revolution (PPR)
• Output Signal: A, B, and Z (index pulse) channels
• Supply Voltage: 5-12 VDC
• Output Type: Open collector or push-pull
• Phase Difference: 90° between A and B channels
• Operating Temperature Range: -10°C to +70°C
• Body Material: Aluminum or plastic (depends on model)
• Degree of Protection: IP64 (dust-tight and splash-resistant)
• Mounting Type: Shaft mount
• Shaft Diameter: 6 mm
• Connection Type: Lead wires or connector (depends on model)
• Weight: Approximately 100 grams
