Omron E6C2-CWZ1X 600P/R Rotary Encoder E6C2CWZ1X

Description:

E6C2CWZ1X600PR2M ROTARY ENCODER 600 P/R 5 VDC 2 M E6C2-CWZ1X is a high-performance incremental rotary encoder designed for precise measurement of rotational position and speed in industrial automation applications. This encoder features a resolution of 600 pulses per revolution, providing accurate and reliable feedback for effective motion control. It includes quadrature outputs (A, B) and an index pulse (Z) for precise position tracking and synchronization. The compact design and durable construction of the E6C2-CWZ1X make it well-suited for integration into machinery and equipment where space is limited and performance is critical.

Technical Specifications:

• Type: Incremental Rotary Encoder
• Resolution: 600 pulses per revolution
• Output Type: Quadrature (A, B) with index pulse (Z)
• Supply Voltage: 5-12 VDC
• Current Consumption: 30 mA or less
• Output Frequency: 100 kHz (max)
• Shaft Diameter: 6 mm
• Mounting: Shaft mount with set screw
• Protection Rating: IP64
• Temperature Range: -10°C to +60°C
• Housing Material: Aluminum (body), plastic (cover)
• Weight: Approximately 150 grams
