Omron E6C3-CWZ5GH 200P/R E6C3CWZ5GH

Description:

The Omron E6A2-CS5C 60P/R rotary encoder is used in industrial automation systems for precise position, speed, and rotational feedback in motion control applications. Commonly installed in conveyor systems, CNC machines, packaging equipment, and robotics requiring accurate shaft position monitoring. Maintenance teams and system integrators use this part for replacement, retrofit, and maintaining reliable motion feedback in automated processes.

Applications:

The Omron E6A2-CS5C rotary encoder is used in industrial environments for speed monitoring, position tracking, and motion synchronization. It is widely applied in factory automation systems, printing machines, material handling equipment, and assembly lines where consistent rotational feedback is essential for process accuracy and control.

Technical Specifications:

• Manufacturer Part Number (MPN): E6A2-CS5C
• Product Type: Incremental Rotary Encoder
• Resolution: 60 pulses per revolution (60 P/R)
• Output Type: NPN open collector
• Supply Voltage: 5 to 24 VDC
• Shaft Type: Solid shaft
• Shaft Diameter: 6 mm
• Maximum Rotation Speed: Up to approx. 5000 rpm
• Connection Type: Pre-wired cable
• Protection Rating: IP50
• Housing Material: Metal body
• Output Signals: A, B phase (quadrature)
• Operating Temperature: -10°C to +70°C
• Mounting Type: Flange mount

Common Replacements:

• Omron E6B2-CWZ6C 60P/R
• Omron E6C2-CWZ6C 60P/R
• Autonics E40S6-60-3-N-24
