Omron E6H-CWZ6C 1000P/R Incremental Type Rotary Encoder 5~24VDC E6HCWZ6C

Description:

The Omron E6H-CWZ6C 1000P/R incremental rotary encoder is used in industrial automation systems for precise position detection and speed feedback in PLC-controlled equipment. Commonly installed in conveyor systems, packaging machines, CNC machinery, and automated assembly lines requiring accurate motion control and rotational monitoring. Maintenance teams and system integrators use this part for replacement, retrofit, and maintaining reliable encoder feedback in automation processes.

Applications:

The Omron E6H-CWZ6C rotary encoder is used in industrial environments where accurate rotational position and speed measurement are essential. It is applied in conveyor synchronization, robotic positioning systems, packaging and labeling machines, and CNC equipment to ensure precise motion control and stable operation within PLC-based automation systems.

Technical Specifications:

• Manufacturer: Omron
• Part Number: E6H-CWZ6C
• Product Type: Incremental Rotary Encoder
• Resolution: 1000 pulses per revolution (P/R)
• Output Type: NPN open collector
• Supply Voltage: 5 to 24 VDC
• Encoder Type: Incremental
• Shaft Type: Solid shaft
• Shaft Diameter: 6 mm (typical)
• Mounting Type: Flange mounting
• Connection Type: Pre-wired cable
• Protection Rating: IP50 to IP65 (model dependent)
• Operating Temperature: -10°C to +70°C

Common Replacements:

• Omron E6C3-CWZ6C 1000P/R Rotary Encoder
• Omron E6B2-CWZ6C 1000P/R Rotary Encoder
• Omron E6F-AG5C-C Rotary Encoder
