Omron R7D-AP04H Servo Drive R7DAP04H

Description:

R7DAP04H SERVO DRIVER 5.5AMP 1 PHASE 200-230VAC 50/60HZ 0-230VAC OUTPUT The R7DAP04H is a high-precision digital input module designed by Omron, intended for integration into industrial automation systems. This module provides four high-speed digital input channels, allowing for rapid and accurate signal processing from various field devices. It is engineered to handle fast input signals and is ideal for use in demanding applications such as high-speed counting, position detection, and process control. Its compact design and robust construction ensure reliable performance and durability in harsh industrial environments. The R7DAP04H module is suitable for various automation tasks, providing flexibility and efficiency in system integration.

Technical Specifications:

• Type: Digital Input Module
• Channels: 4
• Input Type: Sink (NPN) / Source (PNP) (selectable)
• Input Voltage Range: 24 V DC ±20%
• Input Signal Frequency: Up to 1 kHz
• Response Time: 1 ms
• Isolation: 1500 V AC between input and output
• Power Supply: 24 V DC ±10%
• Current Consumption: Approx. 100 mA
• Operating Temperature: 0°C to +55°C
• Environmental Protection: IP20
• Connection: Screw Terminal
• Material: ABS Housing
• Dimensions: 90 mm x 90 mm x 40 mm
