Omron ZEN-20C1DR-D-V2 PLC AUTOMATION ANALOG PROGRAMMABLE RELAY ZEN20C1DRDV2

Description:

ZEN20C1DRDV2 PROGRAMMABLE RELAY ZEN V2 12 INPUTS 8 OUTPUTS STANDARD LCD TYPE W/DISPLAY DC INPUT RELAY OUTPUT 12-24 VDC SUPPLY DIN RAIL MOUNT The Omron ZEN-20C1DR-D-V2 is a compact and versatile PLC automation analog programmable relay designed for a wide range of control and automation tasks. This relay provides flexible programming capabilities and is ideal for applications that require precise control and monitoring. It features built-in analog input and output functions, making it suitable for tasks involving analog signal processing in addition to digital control.

Technical Specifications:

• Model Number: ZEN-20C1DR-D-V2
• Type: Programmable Relay with Analog Functions
• I/O Configuration:
• Digital Inputs: 12 (12V DC)
• Digital Outputs: 8 (Relay output, 250V AC, 5A)
• Analog Inputs: 2 (0-10V, 4-20mA)
• Analog Outputs: 2 (0-10V, 4-20mA)
• Programming Method: Ladder Logic
• Programming Interface: PC with Omron’s ZEN Programming Software
• Supply Voltage: 24V DC
• Power Consumption: Approx. 1000 mW
• Operating Temperature Range: 0°C to 55°C
• Storage Temperature Range: -20°C to 70°C
• Protection Rating: IP20 (for the relay unit itself; ensure proper enclosure for protection)
• Communication: RS-232C (for programming and communication)
• Dimensions: 90 mm (W) x 90 mm (H) x 60 mm (D)
• Weight: Approximately 200 grams
• Features:
• Compact and modular design
• Built-in analog input/output capabilities for more complex control tasks
• Easy-to-use programming interface with ladder logic
• Suitable for various automation tasks and control applications
• High reliability and durability for industrial environments
