Omron ZEN-20C1DT-D-V2 RELAY CONTROLLERS DC 12 ANALOG CPU UNIT PLC MODULE ZEN20C1DTDV2

Description:

The Omron ZEN-20C1DT-D-V2 Relay Controller is a programmable logic controller (PLC) CPU unit used in small-scale industrial automation systems. Commonly installed in control panels, machinery, and building automation systems to execute control logic and manage inputs and outputs. Maintenance teams, OEMs, and system integrators use this unit for replacement, retrofit, and compact automation control solutions.

Applications:

The Omron ZEN-20C1DT-D-V2 Relay Controller is used in industrial and commercial automation systems requiring compact control and logic processing, including machine control, lighting systems, HVAC automation, and small production equipment. It is ideal for applications that demand simple programming, reliable operation, and space-saving control solutions.

Technical Specifications:

• Brand: Omron
• Part Number: ZEN-20C1DT-D-V2
• Product Type: Programmable Relay / PLC CPU Unit
• Series: ZEN V2
• Supply Voltage: 10.8–28.8 V DC
• Number of Inputs: 12 (10 digital + 2 analog)
• Number of Outputs: 8 (transistor outputs)
• Output Type: Solid-state (transistor)
• Programming: Ladder logic (via PC or front panel)
• Display: Built-in LCD with operation buttons
• Communication: RS-485 (model dependent)
• Mounting Type: DIN rail / panel mount
• Expansion: Up to 3 expansion I/O modules
• Operating Temperature: 0°C to 55°C
• Protection Rating: IP20
• Application: Small-scale automation and control systems

Common Replacements:

• Omron ZEN-20C1DR-D-V2
• Omron CP2E-N20DT-D
• Omron ZEN-10C1DT-D-V2
