Regal Beloit Corporation OKR1096 Three-Phase AC Motor

OKR1096 is a Century (Regal Beloit) 1/2-horsepower, three-phase condenser fan motor designed for outdoor HVAC condenser units. Built for continuous-duty operation at 60 Hz, this 56Y-frame motor spins at 1140 RPM and uses a reversible shaft for flexible installation in retrofit and new equipment. It is offered for 208/230 V or 460 V three-phase service, enabling compatibility with common commercial HVAC power schemes. The motor features a Totally Enclosed Air Over (TEAO) enclosure with a 5/8 in. diameter shaft and a 1-7/8 in. long shaft, plus belly-band mounting for straightforward integration into condenser fans. With a current draw around 0.95 A at 460 V and roughly 2 A at 230/208 V, the OKR1096 delivers a practical balance of torque and efficiency for condenser applications, and it carries a service factor of 1.0. The body is a 6-1/2 in. diameter by about 9-1/8 in. overall length package, built with ball bearings for reliable, low-maintenance operation. Applications include replacement or retrofit for outdoor condenser fans in air-conditioning and heat pump systems, where a compact, rugged 56Y-frame motor with reversible rotation and Century's reliability is desirable.
