Schneider Electric PM820UMG POWER METER 820 WITH NO DISPLAY

Description:

The Schneider Electric PM820UMG Power Meter 820 is used in industrial automation and power management systems to monitor electrical parameters in three-phase power distribution networks. This unit is part of the Schneider Electric PowerLogic PM800 series and provides precise measurement of voltage, current, power, energy consumption, and power quality metrics. The PM820UMG version is designed without an integrated display and is typically used in applications where measurements are accessed remotely through communication networks or external monitoring systems. Maintenance teams and system integrators commonly use this meter for energy monitoring, electrical load analysis, and integration into building management or industrial power monitoring systems.

Applications:

The Schneider Electric PM820UMG power meter is commonly used in industrial environments including manufacturing plants, commercial buildings, energy management systems, electrical distribution panels, data centers, and utility monitoring installations where accurate power measurement and energy usage tracking are required.

Technical Specifications:

• Manufacturer: Schneider Electric
• Model: PM820UMG
• Product Type: PowerLogic Power Meter
• Series: PowerLogic PM800
• Measurement Type: Three-phase electrical power monitoring
• Display: No local display (communication-based monitoring)
• Voltage Measurement Range: Up to 690 V AC
• Current Measurement: External current transformers required
• Frequency Range: 45–65 Hz
• Communication Interface: RS-485 Modbus communication
• Accuracy Class: High accuracy energy and power measurement
• Mounting Type: Panel mount module
• Supply Voltage: 100–415 V AC or 125–250 V DC
• Protection Rating: IP52 front panel when mounted
• Operating Temperature Range: −25°C to 70°C
• Function: Electrical power monitoring and energy management

Common Replacements:

• Schneider Electric PM824
• Schneider Electric PM8000 PM8240
• Schneider Electric METSEPM8240
