Schneider Electric XML-A010A2S11 Telemecanique/ Schneider Electric Switch Pressure XMLA010A2S11

Description:

XMLA010A2S11 PRESSURE SENSOR XMLA 10 BAR OPERATING PRESSURE 10 AMP 240 VAC 2% ACCURACY G1/4 FEMALE CONNECTION 4 TERMINALS IP66 The Schneider Electric XMLA010A2S11 is a cylindrical inductive proximity sensor designed for detecting metal objects without physical contact. It provides reliable and precise detection with a sensing range of up to 10 mm, making it suitable for various applications such as position sensing, count monitoring, and object detection in automation systems. The sensor's compact design allows for easy integration into machinery and equipment, while its robust construction ensures durability and performance in demanding industrial environments.

Technical Specifications:

• Type: Inductive Proximity Sensor
• Sensing Range: Up to 10 mm
• Output Type: NPN (Normally Open)
• Operating Voltage: 10-30V DC
• Switching Frequency: Typically up to 1 kHz (consult datasheet for exact frequency)
• Connection Type: Cable with M12 connector
• Degree of Protection: IP67 (suitable for use in harsh environments with protection against dust and water)
• Housing Material: Stainless steel or similar rugged material
• Temperature Range: -25°C to +70°C
• Mounting Type: Typically screw mount or bracket mount
• Dimensions: Approximately 12 mm diameter and 60 mm length (verify exact dimensions from datasheet)
