SICK KTM-WP11182P Replace KT3W-P1116 PLC PHOTOELECTRIC CONTRAST SENSOR KTMWP11182P

Description:

The SICK KTM-WP11182P contrast sensor is used in industrial automation detection and print mark recognition systems. Commonly installed in packaging machines, labeling systems, and printing equipment. Maintenance teams, OEMs, and system integrators use this part for replacement, retrofit, and high-precision contrast detection.

Applications:

The Sick KTM-WP11182P contrast sensor is designed for detecting minimal differences in contrast on materials such as labels, films, and packaging. It is widely used in high-speed packaging lines, printing presses, and labeling machines where accurate mark detection is essential for positioning and synchronization. As a replacement for KT3W series sensors, it offers improved detection performance and reliability in demanding industrial environments.

Technical Specifications:

• Manufacturer: SICK
• Model / Part Number: KTM-WP11182P
• Product Type: Photoelectric Contrast Sensor
• Detection Method: Contrast / mark detection
• Light Source: White LED
• Output Type: PNP switching output
• Output Function: Light/dark switching selectable
• Supply Voltage: 10–30 V DC
• Response Time: < 50 µs
• Switching Frequency: Up to approx. 10 kHz
• Teach-in Method: Dynamic and static teach-in
• Connection Type: M12 connector
• Housing Material: Industrial-grade plastic
• Protection Rating: IP67
• Operating Temperature: -10°C to +55°C
• Mounting: Standard industrial mounting

Common Replacements:

• SICK KT3W-P1116
• SICK KT5W-2P1116
• SICK KTS-WP11182
