Siemens 6AV2124-0MC01-0AX0 SIMATIC HMI KTP700 Basic Panel, 7" Touch/Key, TFT Display

Description:

The Siemens 6AV2124-0MC01-0AX0 is a SIMATIC HMI KTP700 Basic panel designed for user-friendly machine-level visualization and operation. Featuring a 7-inch TFT display with both touchscreen and function keys, this compact HMI supports PROFINET communication and is ideal for basic to mid-level automation tasks. The KTP700 is frequently used in packaging, logistics, and manufacturing systems requiring intuitive user interaction and cost-effective control interfaces.

Technical Specifications:

Manufacturer: Siemens
Series: SIMATIC HMI Basic Panel
Model Number: 6AV2124-0MC01-0AX0
Display Type: 7" TFT color display
Resolution: 800 x 480 pixels (WVGA)
Input: Touchscreen and 8 function keys
Backlight: LED, with adjustable brightness
Interface: 1 x PROFINET (Ethernet), 1 x USB, 1 x MPI/PROFIBUS DP
Power Supply: 24V DC
Flash Memory: 10 MB
Protection Rating: IP65 (front), IP20 (rear)
Mounting: Panel mount
Operating Temperature: 0 to 50 °C (32 to 122 °F)
Dimensions: Approx. 214 x 158 x 47 mm
Weight: Approx. 0.9 kg
