Siemens 6AV6 642-0AA11-0AX1 Simatic Touch Panel 6AV66420AA110AX1
Siemens 6AV6 642-0AA11-0AX1 Simatic Touch Panel 6AV66420AA110AX1
Couldn't load pickup availability





Description:
The Siemens 6AV6642-0AA11-0AX1 is a SIMATIC HMI Basic Panel TP177B 6" touchscreen operator interface, designed for efficient machine-level control and monitoring in industrial automation systems. As part of the SIMATIC HMI TP177B family, it offers a 5.7-inch STN color display, multiple communication ports, and a user-friendly touch interface. Ideal for small to mid-sized applications, this panel supports ProTool and WinCC Flexible engineering tools, making it easy to configure, operate, and integrate into Siemens automation environments.
TECHNICAL SPECIFICATIONS:
Model: 6AV6642-0AA11-0AX1
Series: SIMATIC HMI TP177B
Display Size: 5.7 inches (STN color display)
Resolution: 320 x 240 pixels (QVGA)
Display Colors: 256 colors
Touchscreen: Analog resistive
Backlight: CCFL, replaceable
Processor: ARM-based processor
Memory: 2 MB configuration memory
Interfaces:
1 x RS-422/485 (MPI/Profibus DP)
1 x RS-232
1 x USB
1 x Ethernet (optional with expansion)
Power Supply: 24V DC (19.2 to 28.8V DC range)
Power Consumption: Approx. 6 W
Mounting: Panel mount (flush-mounted)
Software: Supports ProTool and WinCC Flexible
Protection Rating: IP65 (front), IP20 (rear)
Operating Temperature: 0°C to 50°C (32°F to 122°F)
Dimensions: 212 mm x 156 mm x 42 mm (W x H x D)
Cutout Dimensions: 192 mm x 138 mm
Weight: Approx. 0.8 kg (1.76 lbs)
