Siemens 6AV6643-0CD01-1AX1 6AV66430CD011AX1

Description:

6AV66430CD011AX1 DISCONTINUED BY MANUFACTURER OPERATOR INTERFACE 10 INCH DISPLAY TOUCHSCREEN 6 MB MEMORY 24 VDC INPUT 0.8 A REPLACES 6AV6643-0CD01-1AX0 The 6AV6 643-0CD01-1AX1 is a Siemens SIMATIC OP177B operator panel, part of the SIMATIC HMI (Human Machine Interface) family, designed for efficient machine and process control. Featuring a 5.7-inch STN color display, this operator panel supports both touch and key operation, providing a flexible interface for users to monitor and control industrial automation systems. With integrated PROFIBUS DP and MPI communication interfaces, the OP177B is highly suitable for mid-sized automation systems requiring robust performance and user-friendly operation.

Technical Specifications:

• Type: HMI operator panel
• Display Size: 5.7 inches (STN color)
• Resolution: 320 x 240 pixels (QVGA)
• Input Methods: Touchscreen and membrane keys
• Communication Interfaces: PROFIBUS DP, MPI, and RS485
• Memory: 2 MB flash memory
• Input Voltage: 24V DC
• Operating Temperature: 0°C to +50°C
• Protection Rating: IP65 (front), IP20 (rear)
• Mounting Type: Panel mount
• Certifications: CE, UL, and RoHS compliant
• Dimensions: 247 mm x 185 mm x 58 mm (W x H x D)
