Siemens 6AV6647-0AD11-3AX0 HMI Panel 6AV66470AD113AX0

Description:

The Siemens 6AV6647-0AD11-3AX0 HMI Panel is a SIMATIC TP1200 Comfort touchscreen operator interface used in industrial automation systems for visualization and control of machines and processes. Commonly installed in manufacturing control panels, process automation systems, and machine interfaces where advanced operator interaction and real-time data display are required. Maintenance teams and system integrators use this panel for replacement, retrofit, and system upgrades to improve operator usability and system diagnostics.

Applications:

The Siemens 6AV6647-0AD11-3AX0 HMI panel is widely used in industrial automation environments to monitor and control equipment, visualize process data, and interact with PLC programs. It is deployed in production plants, packaging systems, robotics cells, water/wastewater facilities, and material handling systems to display alarms, trends, and operational status while allowing operator input. With integrated communication interfaces and powerful visualization features, it supports complex machine interaction and operator efficiency.

Technical Specifications:

• Manufacturer: Siemens
• Model / Part Number: 6AV6647-0AD11-3AX0
• Product Type: HMI Operator Panel (TP1200 Comfort)
• Display Size: 12.1‑inch widescreen touchscreen
• Resolution: 1280 × 800 pixels
• Colors: 16 million+
• Operation: Touchscreen interface with ergonomic UI
• Communication Interfaces: PROFINET, MPI, PROFIBUS, Ethernet
• Additional Ports: USB for data transfer and backup
• Supply Voltage: 24 V DC
• Protection Rating: IP65 front / IP20 rear
• Mounting: Panel mount
• Operating Temperature: Industrial range
• Application: Industrial machine visualization and control

Common Replacements:

• Siemens 6AV2124‑0MC01‑0AX0 (TP1200 Comfort variant)
• Siemens 6AV2124‑0GC01‑0AX0 (TP700 Comfort)
• Siemens 6AV6643‑0CD01‑1AX1 (MP277 HMI)
