Siemens 6ES7135-6HD00-0BA1 Module in 6ES71356HD000BA1

Description:

6ES71356HD000BA1 ANALOG OUTPUT MODULE SIMATIC ET 200SP AQ 4XU/I STANDARD 16 BIT SUITABLE FOR BU TYPE A0 MODULE DIAGNOSTICS The Siemens 6ES7135-6HD00-0BA1 is a high-performance analog input module designed for use with the S7-1500 PLC series. It provides 8 analog input channels with 16-bit resolution, capable of measuring both voltage (0-10V) and current (0/4-20mA) signals with high precision. This module is equipped with built-in diagnostics to ensure accurate signal measurement and reliability in industrial environments. Its robust design and high measurement accuracy make it suitable for complex control and monitoring applications, enabling seamless integration and expansion of the S7-1500 PLC system’s analog input capabilities.

Technical Specifications:

• Product Type: Analog Input Module
• Series: S7-1500
• Catalog Number: 6ES7135-6HD00-0BA1
• Number of Inputs: 8
• Input Types:
• Voltage: 0-10V
• Current: 0/4-20mA
• Input Resolution: 16 bits
• Accuracy: ±0.1% of full scale
• Sampling Rate: 1 ms (per channel)
• Isolation: 500V (channel-to-channel and channel-to-bus)
• Diagnostic Indicators: LEDs for input status
• Operating Temperature Range: 0°C to 60°C
• Storage Temperature Range: -40°C to 85°C
• Relative Humidity: 5% to 95%, non-condensing
• Power Supply: Typically powered by the PLC system
• Mounting Type: DIN rail
• Dimensions (W x H x D): Approximately 40 mm x 125 mm x 120 mm
