Siemens 6ES7365-0BA01-0AA0 INTERFACE MODULE 6ES73650BA010AA0

Description:

6ES73650BA010AA0 PLC MODULE SIMATIC S7-300 CONNECTION INTERFACE MODULE IM 365 FOR CONNECTION OF AN EXTENSION RACK WITHOUT C BUS 2 MODULES 1M CONNECTING CABLE The Siemens 6ES7 365-0BA01-0AA0 is a compact and reliable digital output module designed for the S7-300 PLC series. This module provides 8 digital output channels, each capable of delivering 24V DC signals with a maximum current load of 0.5A per channel. It features built-in diagnostics with LED indicators to display the status of each output, simplifying monitoring and troubleshooting. The 6ES7 365-0BA01-0AA0 is engineered for dependable performance in industrial environments, offering precise control for various actuators and output devices in automation systems.

Technical Specifications:

• Product Type: Digital Output Module
• Series: S7-300
• Catalog Number: 6ES7 365-0BA01-0AA0
• Number of Outputs: 8
• Output Voltage: 24V DC
• Output Current: 0.5A per channel
• Response Time: 1 ms (typical)
• Isolation: 500V (channel-to-channel and channel-to-bus)
• Diagnostic Indicators: LEDs for output status
• Mounting Type: DIN rail
• Dimensions (W x H x D): Approximately 40 mm x 125 mm x 120 mm
• Operating Temperature Range: 0°C to 60°C
• Storage Temperature Range: -40°C to 85°C
• Relative Humidity: 5% to 95%, non-condensing
