Siemens PLC 6ES7 216-2BD23-0XB0 6ES7216-2BD23-0XB0

Description:

The Siemens 6ES7 216-2BD23-0XB0 is a compact digital output module from the SIMATIC S7-1200 series, specifically the SM 1223 line. Designed for seamless integration into automation systems, it provides 16 digital outputs (relay-type) for controlling various field devices. This module is ideal for use in general-purpose automation tasks such as controlling lights, actuators, or relays in industrial environments. With easy DIN rail mounting and compatibility with the TIA Portal software, it offers a flexible and reliable solution for expanding I/O capabilities.

TECHNICAL SPECIFICATIONS:

Model: 6ES7 216-2BD23-0XB0
Series: SIMATIC S7-1200, SM 1223
Function: Digital Output Module
Number of Outputs: 16 (Relay)
Output Type: Relay (electromechanical)
Operating Voltage: 24V DC / 230V AC max
Output Current: 2 A per channel, 8 A total per group
Isolation: Optically isolated
Status Indicators: LED per channel
Connection Type: Screw terminals
Mounting: DIN rail
Protection Class: IP20
Operating Temperature: –20°C to +60°C (–4°F to 140°F)
Dimensions: Approx. 90 mm x 100 mm x 75 mm (H x W x D)
Weight: Approx. 400 g (0.88 lbs)
