Teradyne 949-824-00 PCI Data Acquisition Board

Description:

The Teradyne 949-824-00 PCI Data Acquisition Board is used in automated test equipment (ATE) to acquire, transfer, and process test data between PCI-based host systems and electronic test hardware. Commonly installed in Teradyne Catalyst automated test systems, semiconductor test equipment, and electronic control assemblies utilizing compatible PCI data acquisition boards. Maintenance technicians, OEM service providers, and system integrators use this PCI data acquisition board for replacement, electronic repairs, and restoring reliable data acquisition and communication performance.

Applications:

The Teradyne 949-824-00 PCI Data Acquisition Board is used in compatible Teradyne Catalyst automated test equipment and semiconductor testing systems. It is commonly replaced during data acquisition system maintenance or interface board repairs to restore reliable equipment operation.

Technical Specifications:

• Manufacturer Part Number (MPN): 949-824-00
• Brand: Teradyne
• Product Type: PCI Data Acquisition Board
• Model: LA824
• Board Type: PCI Adapter / Data Acquisition Board
• PCI Form Factor: PCI Compatible
• Bus Transceivers: 4 Quadruple Bus Transceivers
• Bi-Directional Transceivers: 16-Bit
• Primary Function: Acquires and transfers test data between the host computer and automated test equipment
• System Compatibility: Compatible Teradyne Catalyst Automated Test Equipment (ATE)
• Typical Equipment: Teradyne Catalyst semiconductor test systems and electronic test platforms
• Installation Type: PCI Slot Expansion Board
• Replacement Purpose: Faulty or damaged PCI data acquisition board replacement

Common Replacements:

• Teradyne LA824 Adapter Board (949-824-00/C)
• Teradyne 949-824-00/E PCI Data Acquisition Board
• Teradyne PCI Interface Adapter Board
