Toyogiken BOXTM-221-F0S0-HI Terminal Box Enclosure

Description:

The TOGI BOXTM-221-F0S0-HI Terminal Box Enclosure is used in industrial electrical wiring systems to protect terminal block connections in harsh environments. Commonly installed in control panels, machine tools, factory automation equipment, and industrial machinery. Maintenance teams, OEMs, and system integrators use this terminal box enclosure for new installations, replacement, retrofit, and electrical wiring maintenance.

Applications:

The TOGI BOXTM-221-F0S0-HI Terminal Box Enclosure is designed for industrial control and power distribution applications requiring a sealed, high-capacity terminal enclosure. It is suitable for manufacturing equipment, automation systems, and outdoor or washdown environments where IP67 protection is required.

Technical Specifications:

• Manufacturer Part Number (MPN): BOXTM-221-F0S0-HI
• Alternate Reference: #315473
• Brand: TOGI
• Product Type: Terminal Box Enclosure
• Series: BOXTM Series
• Terminal Block: 22 Poles (M3.5)
• Rated Voltage: 600 VAC/DC
• Rated Current: 15 A
• Protection Rating: IP67
• Cover Type: High Cover, Opaque (PBT)
• Front Cable Entry: None (F0)
• Side Cable Entry: None (S0)
• Mounting: Direct Mounting / DIN Rail Mounting Compatible
• Insulation Resistance: 100 MΩ minimum (DC 500 V)
• Withstand Voltage: AC 2500 V for 1 Minute
• Applicable Wire Size: Up to 2.0 mm²
• Tightening Torque: 0.8–1.4 N·m (Terminal Screw)
• Ambient Temperature: -25°C to +100°C (No Freezing or Condensation)
• Housing Material: PBT (UL94 V-0)
• Gasket Material: NBR
• Lid Screw Material: Stainless Steel (SUS)
• Dimensions (W × D × H): 150 × 124 × 106.5 mm
• Approximate Weight: 475 g
• Manufacturer: Toyogiken Co., Ltd.
• Country of Origin: Japan

Common Replacements:

• TOGI BOXTM-221-F0S0-HC
• TOGI BOXTM-221-F2S0-HI
• TOGI BOXTM-220-F0S0-HI
