TR Electronic CEH80M-00044 Multiturn Absolute Rotary Encoder

Description:

The TR Electronic CEH80M-00044 is a multiturn absolute rotary encoder designed to provide high-resolution position feedback for motion control and industrial automation systems. Operating from 10–30 VDC and providing 4,096 steps per revolution, it delivers reliable absolute position data for precise machine control without requiring homing after power loss. Commonly installed in CNC machines, packaging equipment, conveyors, robotics, and material handling systems, it is used by maintenance technicians, OEM machine builders, and system integrators for equipment replacement, retrofit projects, and restoring accurate machine positioning.

Applications:

The TR Electronic CEH80M-00044 is used in industrial automation systems requiring accurate multiturn rotary position feedback. It is suitable for CNC machinery, automated production lines, packaging equipment, conveyor systems, printing presses, robotics, and material handling equipment where dependable position monitoring improves machine accuracy, repeatability, and process control.

Technical Specifications:

• Manufacturer Part Number (MPN): CEH80M-00044
• Alternate Part Number: CEH80M00044
• Manufacturer: TR Electronic
• Product Type: Absolute Rotary Encoder
• Encoder Type: Optical Multiturn Absolute Encoder
• Resolution: 4,096 steps per revolution
• Number of Revolutions: Model dependent (multiturn series)
• Supply Voltage: 10–30 VDC
• Interface: SSI (model-specific)
• Output Level: RS-422
• Code: Programmable
• Housing Diameter: 80 mm
• Shaft Type: Hollow shaft (configuration dependent)
• Protection Rating: IP54
• Operating Temperature: 0°C to +60°C (optional -20°C to +70°C)
• Maximum Mechanical Speed: 3,000 RPM
• Compatible Equipment: PLC systems, CNC machines, packaging machinery, conveyors, robotics, and industrial automation equipment
• Installation Type: OEM replacement absolute rotary encoder
• Application Environment: Industrial automation, manufacturing, machine control, material handling, and motion control applications

Common Replacements:

• TR Electronic CEH80M-00044 Absolute Rotary Encoder
• TR Electronic CEH80M Series Absolute Encoder
• TR Electronic CEH802 Series Absolute Rotary Encoder
